11 - 4
COMM LED
This is the communication LED. It indicates the status of data transfer between the Dolphin
terminal and the host device.
Back Panel
Auxiliary Battery Well
The base enables you to charge an additional battery pack independently of the terminal well
in 4 hours for the standard battery or 6 hours for the extended battery. This feature ensures
that you can always have a fully-charged battery for your terminal. See Charging a Spare
Battery in the Auxiliary Battery Well on page 11-6.
USB Port
This USB port is USB v2.0 Hi-Speed (480 Mbps) compliant. Using a USB cable, you can
connect the base to a host device, such as a workstation. When the terminal is seated in the
terminal well, it is connected to the host device via the base. See Communication on page 11-
7.
DC Power Jack
See Power on page 11-5.
This color means…
Green A USB Connection is established with the host workstation.
Auxiliary Battery Well
DC Power Jack
USB Port
