3 - 1
3
Hardware Overview
Standard Configurations for the Dolphin 70e Black
WLAN, WPAN & Camera
• Android 4.0
• TI OMAP3715 1.0GHz Processor
• 512MB RAM X 1GB Flash
• 3.7V Li-ion rechargeable standard or
extended battery pack
• Dedicated imager capable of decoding
standard 1D and 2D bar code symbologies
• 5.0 megapixel auto focus color camera
• 802.11a/b/g/n and Bluetooth
WLAN, WPAN, WWAN, GPS & Camera
• Android 4.0
• TI OMAP3715 1.0GHz Processor
• 512MB RAM X 1GB Flash
• 3.7V Li-ion rechargeable standard or
extended battery pack
• Dedicated imager capable of decoding
standard 1D and 2D bar code symbologies
• 5.0 megapixel auto focus camera
• 802.11a/b/g/n and Bluetooth,
• Voice and Data, GSM/CDMA/GPS - SW
Definable Radio
WLAN, WPAN, WWAN, NFC, GPS & Camera
• Android 4.0
• TI OMAP3715 1.0GHz Processor
• 512MB RAM X 1GB Flash
• 3.7V Li-ion rechargeable standard or
extended battery pack
• Dedicated imager capable of decoding
standard 1D and 2D bar code symbologies
• 5.0 megapixel auto focus color camera
• 802.11a/b/g/n and Bluetooth
• Voice and Data, GSM/CDMA/GPS - SW
Definable Radio
• Near Field Communication (NFC) support
WLAN, WPAN, WWAN, GPS & Camera
• Android 4.0
• TI OMAP3715 1.0GHz Processor
• 512MB RAM X 1GB Flash
• 3.7V Li-ion rechargeable standard or
extended battery pack
• Dedicated imager capable of decoding
standard 1D and 2D bar code symbologies
• 5.0 megapixel auto focus camera
• 802.11a/b/g/n and Bluetooth
• Voice and Data GSM/GPS
WLAN, WPAN, WWAN, NFC, GPS & Camera
• Android 4.0
• TI OMAP3715 1.0GHz Processor
• 512MB RAM X 1GB Flash
• 3.7V Li-ion rechargeable standard or
extended battery pack
• Dedicated imager capable of decoding
standard 1D and 2D bar code symbologies
• 5.0 megapixel auto focus camera
• 802.11a/b/g/n, and Bluetooth
• Voice and Data, GSM/GPS
• Near Field Communication (NFC) support
