15 - 3

Parts and Functions

Front Panel

Terminal Wells

The base contains four terminal wells, which offer independent battery charging for each

docked terminal.

DOCK LEDs

The Dock LED indicates if the terminal is properly seated in the charging well. Each well has

a dedicated Dock LED, which illuminates blue when a terminal is properly seated in the

charging well.

Dock LED (Qty. 4)

Terminal Wells (Qty. 4)
